| Mobile Module | |
|---|---|
| Technology | 4G (LTE) - Cat 1 up to 10 Mbps, 3G - Up to 42 Mbps, 2G - Up to 236.8 kbps |
| Power | |
| Connector | microUSB |
| Input Voltage Range | 5V - powered via microUSB |
| Power Consumption | 3.2 W Max |
| Physical Interfaces | |
| Status LEDs | 1 x Power LED, 1 x Network LED, 1 x LTE LED |
| SIM | 1 x SIM slot (Mini SIM - 2FF), 1.8 V/3 V |
| Power | 1x microUSB |
| Antennas | 1 x SMA for LTE |
| Physical Specification | |
| Dimensions (W x H x D) | 74.5 x 25 x 64.5 mm |
| Casing Material | Aluminium housing |
| Weight | 131 g |
| Mounting Options | DIN rail, Flat surface |
| Operating Environment | |
| Operating Temperature | -40 °C to 75 °C |
| Operating Humidity | 10% to 90% non-condensing |
| Ingress Protection Rating | IP30 |
| TRM Software (Management Software) | |
| Supported Operating Systems |
|
| Regulatory & Type Approvals | |
| Certifications | CE, UKCA, EAC, UCRF, Kenya, ICASA |
| EMC Emissions & Immunity | |
| Standards | Draft EN 303 446-1 V1.1.0 |
| ESD | EN 61000-4-2:2009 |
| Radiated Immunity | EN IEC 61000-4-3:2006 + A1:2008 + A2:2010 |
| RF | |
| Standards |
|
